表面粗糙度
工作臺面尺寸	-
主機重量	-
錐度	-
最大承重	-
最大功耗
最大切割厚度	-
最大加工速度	100
工作油糟尺寸	-
工作臺行程（X*Y）	-
Z軸行程	-
主機裝箱尺寸
最大加工電流
最小電極消耗比
品牌	泰州創源
型號	DK7735

加工定制：	是	品牌：	創源
型號：	DK7735	適用行業：	通用
工作臺面尺寸：	740*470mm	工作臺行程（X*Y）：	350*450mm
Z軸行程：	400-500mm	**大切割厚度：	500（mm）
錐度：	6°/80mm	**大承重：	450kg
主機裝箱尺寸：	1460*950*1600mm	**大加工速度：	100（mm/min）



型號 type	工作臺面尺寸 worktable	工作臺行程 table travel	**大切割厚度 max.thickness	加工錐度 machined taper	**大承載重量 max.carrying capacity	主機外型尺寸 overall dimensions
DK7725	400*579mm	250*320mm	300mm	0-±3°	300kg	1240*900*1600mm
DK7732	680*440mm	320*400mm	400-500mm	6°/80mm	400kg	1430*900*1600mm
DK7735	740*470mm	350*450mm	400-500mm	6°/80mm	450kg	1460*950*1600mm
DK7740	760*540mm	400*500mm	400-500mm	6°/80mm	600kg	1560*1100*1600mm
DK7745	920*540mm	450*630mm	400-500mm	6°/80mm	750kg	1560*1200*1700mm
DK7750	1000*640mm	500*630mm	500mm	6°/80mm	750kg	1680*1250*1700mm
DK7750F	1147*655mm	500*800mm	600-800mm	6°/80mm	800kg	1680*1390*1700mm

 泰州創源機床有限公司地處風景秀麗、交通便捷的泰州經濟開發區，東傍寧靖鹽高速、南靠寧通高速，北依寧啟鐵路。公司是生產精密數控機床的專業廠家，憑鑒精良的加工設備，雄厚的技術力量，精湛的工藝。在進一步增強與國內科研機構和高等院校合作的同時，不斷開發設計出結構完整，品**良，功能齊全的數控電火花線切割機床。公司以“貨真價值、服務周到、共同發展”的經營方針，在市場上贏得了良好的聲譽，在全國各省市，設有分公司和銷售服務機構，能為用戶及時提供信息咨詢、配件、易消耗品及各種售后服務。
    公司生產的DK系列線切割機床有DK77150、DK77120、DK77100、DK7780、DK7763、DK7750、DK7740、DK7732、DK7725等多種型號，本公司可以根據貴公司的要求定做超大型機床。主要采用精密滾珠絲杠，精密鑲鋼V型導軌、機械傳動精度高，機床具有6°、12°、20°、30°等多種錐度加工的功能。機床控制柜集計算機，機床電氣、脈沖電源為一體控制。主機有單板機及微機，微機控制系統可編程與加工控制同時進行?？刂葡到y(tǒng)具有自動找中心、結束停機、短路回退、斷絲停電回原點，停電記憶恢復加工，圖形軌跡跟蹤顯示，任意角度旋轉加工等控制功能。
    本企業在新的世紀里，正以現代化經營理念，科學的管理水平，博采眾長、銳意進取、秉持至真、至誠、至信的營銷作風，為客戶生產出更**的產品，提供更完善的服務。竭誠歡迎廣大新老客戶和廠商惠顧，任意選購，來電來函來人，洽談會晤。

    Taizhou ChuangYuan Machine Tools Co., Ltd. is located in beautiful scenery and convenient traffic Taizhou Economic Development Zone, East side of salt ningjing high-speed, high-speed Ningtong the south, the north railway Ningqi. Is a precision CNC machine tool production of professional manufacturers, with excellent Kam-processing equipment, abundant technical strength, exquisite technology. Further enhanced with the cooperation between research institutions and institutions of higher learning at the same time, and constantly develop the integrity of the structure design, high quality, full-featured CNC WEDM. Company to "true value of goods, service and common development" operating principles, and in the market to win a good reputation, provinces and cities in the country, with branch offices and sales services, users can provide timely information, accessories, easy consumables and various after-sales service.
   DK series produced by WEDM have DK77150, DK77120, DK77100, DK7780, DK7763, DK7750, DK7740, DK7732, DK7725, such as a variety of models, the Company in accordance with the requirements of your custom-made super-large machine tools. The main use of precision ball screws, precision inlaid steel V-rail, high-precision mechanical transmission, machine tools with a 6 °, 12 °, 20 °, 30 ° taper and other processing functions. Machine computer control cabinet, electric machine, pulse power supply for integrated control. SBC and the host computer has, microcomputer control system programmable control and processing at the same time. With automatic control system to find center, the end of shutdown, short circuit back to back, broken wires in power back to the starting point, the resumption of processing power and memory, graphics trajectory tracking show that any angle rotation control processing.
    The enterprise in the new century is a modern management concept, scientific management, absorbing, forge ahead, to uphold truth, sincerity, to the marketing style of the letter for customers to produce better products, provide better services . We welcome the broad masses of old and new customers and vendors patronage, any purchase, call letters come, Fair met.
