出料粒度	0.15
進料粒度	02-3
生產能力	≤25
適用物料	礦石
外形尺寸	00
新舊程度	全新
應用領域	礦石
原理	制樣粉碎機
重量	180
粉碎程度	細磨機
物料含水量	00
最大物料硬度	00
品牌	綠洲
型號	各種
加工定制	是

試驗室圓盤破碎機技術參數 Technical Parameter of laboratory sealed Disk Crushers 主要供煤電、電力、礦山、地質、化工、冶金、建材及化工等行業物料粉碎制樣，替代手工磨樣。自動除塵、無污染、適用室內作業。本產品由原地礦部**指定企業生產，執行行業標準。 該機結構緊鄒，密封性能好、清掃方便、剛度大、體積小、重量輕、并裝備有調整數值刻度機構等優點。用于破碎給類中等硬度的礦石和物料。 Laboratory Sealed Disk Cruhsher and Vertical pulverizer are applicable to comminution of coal,bauxite and other materials in labs of mine,coal preparation plant,coking plant,power plant,chemical plant,reseatch institute and institutions of higher leaning for making samples instead of grinding samples manually.They are suitable to be operated indoors with automatic removal of dust and no pollutions prodused.The products are produced by the only enterprise designated by the former Ministry of Geology and Mineral Resources,in compliance with the Industrial standards.

型號Model	處理量Capacity	圓盤直徑Disk Dia diamete	給料粒度Feed size	排料粒度Output size	圓盤轉速Rotating speed	功率Power	重量Weight
	Kg/h	mm	mm	mm	r/min	kw	kg
XPF 175	≤25	175	2-3	0.15	940	1.1	180
XPF 175T	≤35	175	4-6	0.07	940	1.1	180
XPF 175Z	≤35	175	4-6	0.07	940	1.1	180
XPF 150B	≤60	150	6	0.2-0.074	1050	1.1	95
MP 175	≤35	175	6	0.2-0.074	980	1.5	130
MP 200	≤35	200	8	80-100目	950	2.2	150
MP 250	≤160	250	8	3-0.074	800	2.2	165
MP 300	≤100	300	10	0.4	800	4	195
